Cub Cadet HDS 6284 54AD74HD603 (2007) Fender, Foot pad Listas de piezas de repuesto y dibujos

Fender, Foot pad 54AD74HD603 (2007)

Cub Cadet Compact tractors HDS 6284 54AD74HD603 (2007) Fender, Foot pad
PosNúmero de artículoDescripción
1 631-04006ACOVER FENDER LH
2 631-04169COVER-RH FENDER W/HOLE 6000SER
3 703-05271BRKT-MIRROR ROD
4 703-05296GATE-HI LO SHIFT RH
5 703-05297GATE-PTO SHIFT LH
6 703-3451ABRACKET-LH SEAT MTG
7 703-3572BRKT-RH SEAT MTG
8 703-3754ABRACKET-REAR SEAT MTG
9 Cub Cadet SCR:HL:1/4-15:0.750:HXINDWSH710-0895SCR:HL:1/4-15:0.750:HXINDWSH
10 710-0971SCREW-TRUSS PHIL HD
11 Cub Cadet SCR:HL:5/16-14:.750:TRUSPHI710-1242SCR:HL:5/16-14:.750:TRUSPHI
12 Cub Cadet SCR:TT:5/16-18:0.750:HXINDWSH710-1260ASCR:TT:5/16-18:0.750:HXINDWSH
13 Cub Cadet SCREW HHCS:5/16-18:.75:GR5:STD710-3008SCREW HHCS:5/16-18:.75:GR5:STD
14 710-3038SCRE.HHCS:5/16-18:.875:GR5:STD
15 710-0604SCREW TT:5/16-18:0.625HXINDWSH
16 710-3021710-3021
17 Cub Cadet SCRE.HHCS:5/16-18:2.00:GR5:STD710-3103SCRE.HHCS:5/16-18:2.00:GR5:STD
18 711-04183ROD:MNT:MIR
19 Cub Cadet NUT:HEXLK:5/16-18:GR5:NYLON712-0429NUT:HEXLK:5/16-18:GR5:NYLON
20 712-3061NUT-INSERT
21 720-04029MIRROR-SIDE:CE
22 726-0211NUT:U:5/16-18
23 Cub Cadet MOUNTING CLIP:.250 DIA726-3046MOUNTING CLIP:.250 DIA
24 731-04513COVER-HAND BRAKE
25 731-3324ACOVER-FOOTBOARD CNTR YELO 7000
26 731-04086AFDR:7000:EURO
27 735-0669PAD-RH FOOTBOARD
28 735-0670PAD-LH FOOTBOARD
29 735-0690GROM:.4375 ID x .750
30 736-0275WASH:FLAT:.344 x .688 x.065
31 750-3310SPCR-FLG:.3125 X.4375 X.625
